2.Installation

23

Network configuration

Configure the IP address and wireless settings. Select Network under
Configuration in the Web page.

* Required for both Transmitter and Receivers

TIP

- The MVDS transmitter and receivers operate without the need to manually configure an IP

address as they supports Auto IP function.

- It is impossible to broadcast a movie across a router.

Configure these settings according to your network environment (by default,
DHCP and the Auto IP function are enabled).

Select Enable for the Wireless Interface. Select the options for Wireless Mode,
SSID, WEP, etc. appropriate for your environment.

TIP

- Be sure to use WEP security, especially if you are using MVDS with a public wireless network.
