3.Monitor and Maintenance
37
Shows the service status for each data transfer.
SERVICE ACTIVITY
SERVICE ACTIVITY (sample)
SERVICE:VIDEO
ACTIVE 1280x768 Selected menu
Current status of the selected menu
Menu options and status
Menu Description Status Definition
VIDEO
Displays a service status for
video data transfer. ACTIVE ****x***
Video data is being transferred.
The detected resolution is also
displayed.
NO SIGNAL No video data is input.
AUDIO
Displays the service status for
audio data transfer.
ACTIVE STEREO Audio data is being transferred.
WAIT VIDEO SYNC
Waiting for synchronization with
video data.
SERIAL
Displays the service status for
serial data transfer. READY Serial data transfer is ready.
ACTIVE Serial data has been transferred.
