1.Product Overview
7
1.2.3 Interface specification
Interface specification is as follows:
Video
Interface Analog RGB (15pin Dsub)
Codec JPEG2000
Resolution 1280 x 768 pixel (WXGA)
Flame rate 30 fps (MAX)
Configuration Video Adjustment(Contrast , Bright , Position etc…)
Others Startup screen, Stop signal screen, Maintenance screen
(Display a still image specified in each mode.)
Audio
Interface Stereo mini jack
Codec 16bit PCM
Sampling rate 32 (KHz)
Serial Data
Baud rate 300 , 600 , 1200 , 2400 , 4800 , 9600 , 14400 , 19200 , 38400 , 57600 , 115200 (bps)
Bit length 8 , 7 (bit)
Stop bit 1 , 2 (bit)
Parity NONE , EVEN , ODD
Flow Control NONE , XON/XOFF , RTS/CTS
Timeout 50 to 1000(ms)
