Product overview
5
Product overview
Overview of the EM 300 receiver
A
B
543.200
SKM300
ew300 G3
B.Ch: 20.24
PEAK
MUTE
EQ:
+ 12dB
P
-10
0
40
30
20
10
-20
-30
-40
AF
RF
MHz
´
²
¶
¿
»
·
³
º
¾
µ
¹
¸
ƹ
Ƹ
ƺ ƻ
Operating elements – front panel
Operating elements – rear panel
³
Headphone output,
¼” (6.3 mm) jack socket (
)
·
Headphone volume control
»
button, backlit
¿
Infra-red interface
´
Display panel, backlit in orange
²
Jog dial
¶ STANDBY
button,
serves as the ESC (cancel) key in the
operating menu
º
Antenna input II (
ANT II
) with
remote power supply input,
BNC socket
¾
Type plate
µ
Antenna input I (
ANT I
) with
remote power supply input,
BNC socket
¸
Audio output (
AF OUT UNBAL
),
¼” (6.3 mm) jack socket,
unbalanced
¹
Audio output (
AF OUT BAL
),
XLR-3M socket, balanced
Ƹ
LED (yellow) for network activity
indication
ƹ
LAN socket (
ETHERNET RJ-45
)
ƺ
Cable grip for power supply DC cable
ƻ
DC socket (
DC IN
) for connection of
NT 2-3 mains unit
A
B
