Using the devices
17
̈
Screw the desired microphone head to the radio microphone.
̈
Put the radio microphone back into operation.
Changing the color-coded protection ring
The color-coded protection ring
¾
prevents the multi-function switch
¹
from accidental
operation. Protection rings in different colors are available as accessories. The protection
rings allow you to clearly identify each radio microphone.
̈
Remove the color-coded protection ring as shown in the left-hand diagram.
̈
Put on a new protection ring as shown in the right-hand diagram.
Using the devices
To establish a transmission link, proceed as follows:
1. Switch the receiver on.
2. Switch a transmitter on.
The transmission link is established and the and the display backlighting of the receiver
changes from red to orange.
If you cannot establish a transmission link between transmitter and receiver:
̈
Make sure that transmitter and receiver are set to the same frequency bank and to the
same channel.
̈
If necessary, read the chapter “If a problem occurs ...” on page 30.
Do not touch the contacts of the radio microphone nor the contacts of the micro-
phone head. The contacts can become dirty or damaged if touched.
When unscrewing the microphone head during operation, the muting function is
automatically activated. “
MUTE ” appears on the display panel.
When screwing the microphone head back to the radio microphone, the muting
function is deactivated.
¾ ¾
º º
