Overview of the operating menus
27
Equalizer Changes the frequency response of the output signal
Auto Lock Activates/deactivates the automatic lock mode
Advanced Calls up the extended menu “ Advanced Menu ”
Exit Exits the operating menu and returns to the current standard display
“Easy Setup”
Reset List Releases all locked frequency presets and selects an unused frequency preset
Current List Selects an unused frequency preset
Scan New List Scans for unused receiving frequencies (frequency preset scan)
Exit Exits the submenu “ Easy Setup ” and returns to the main menu
Extended menu “Advanced Menu”
Tune Sets the receiving frequencies for the frequency banks “ U1 ” to “ U6 ”
Special function: Sets a channel and a receiving frequency for the frequency banks “ U1 ” to
“ U6 ”:
̈ Select this menu item and call it up by pressing the jog dial ² until the channel
selection appears.
Sync Settings Activates/deactivates the parameters to be transferred to the transmitters
Pilot Tone Activates/deactivates the pilot tone evaluation
Warnings Activates/deactivates the warning messages
LCD Contrast Adjusts the contrast of the display panel
Reset Resets the receiver
IP-Address Adjusts the IP address of the receiver
Software Revision Displays the current software revision
Exit Exits the extended menu “ Advanced Menu ” and returns to the main menu
Submenu “Sync Settings”
SKM Settings Activates/deactivates the parameters to be transferred to the SKM radio microphones
SK Settings Activates/deactivates the parameters to be transferred to the SK bodypack transmitters
Exit Exits the submenu “ Sync Settings ” and returns to the extended menu “ Advanced Menu ”
“SK Settings”/“SKM Settings”
Here you can activate/deactivate the transfer of the following transmitter parameters: Sensitivity, Auto Lock, Mute
Mode and RF Power
(see page 28)
“Warnings”
Activates/deactivates warnings (color change and warning messages):
AF-Peak Audio overmodulation
Low RF-Signal RF signal is weak
RF-Mute RF signal is too weak or no RF signal
TX-Mute • Transmitter is muted or
• no pilot tone
RX-Mute Receiver is muted
Low Battery Charge status of the transmitter battery/the BA 2015 accupack is critical
Exit Exits the submenu “ Warnings ” and returns to the extended menu “ Advanced Menu ”
Display Function of the menu item
