Putting the devices into operation
14
SK 300 bodypack transmitter
Inserting the batteries/accupack
For powering the bodypack transmitter, you can either use two 1.5 V AA size batteries or the
rechargeable Sennheiser BA 2015 accupack.
̈
Push the two catches
¹
in the direction of the arrows and open the battery compart-
ment cover
¸
.
̈
Insert the two batteries or the accupack as shown above.
Observe correct polarity when inserting the batteries/accupack.
̈
Close the battery compartment.
The battery compartment cover
¸
locks into place with an audible click.
Charging the accupack
To charge the BA 2015 accupack:
̈
Insert the bodypack transmitter into the L 2015 charger (optional accessory).
Connecting the microphone cable/line cable
The audio input is designed for the connection of both condenser microphones and other
audio sources. DC powering of the condenser microphones is via the audio input.
̈
Use one of the recommended Sennheiser microphones or the optional CL 2 line cable.
̈
Connect the 3.5 mm jack plug
ƻ
from the Sennheiser microphone or line cable to the
3.5 mm jack socket MIC / LINE
³
.
̈
Lock the 3.5 mm jack plug by screwing down the coupling ring
Ƽ
of the cable.
̈
Via the operating menu, adjust the sensitivity of the microphone/line input.
The L 2015 charger can only charge the combination BA 2015 accupack/bodypack
transmitter. Standard batteries (primary cells) or individual rechargeable battery
cells cannot be charged.
¸
¸
¹
³ Ƽ ƻ
