1.4
Understanding Component
Locations
These are the main components of your machine:
Front View
Document
Guides
Document
Input Tray
Document
Cover
Automatic
Document Feeder
Paper Output
Extension
Toner
Cartridge
Optional Paper
Tray (Tray 2)
USB Flash
Drive Port
Document
Output Tray
Control Panel
Paper Level Indicator
Front Door
Front Output Tray
(Face Down)
Paper Tray
(Tray 1)
Multipurpose Tray
Document Glass
