Instructions for the user

28

3

DESCRIPTION OF CONTROLS

All the cooker controls and commands are on the front panel.

FRONT RIGHT-HAND
COOKING ZONE

OVEN THERMOSTAT

REAR RIGHT-HAND
COOKING ZONE

OVEN FUNCTIONS

REAR LEFT-HAND
COOKING ZONE

FRONT LEFT-HAND
COOKING ZONE

Before using the oven check that the electronic programmer is showing the symbol

; see paragraph

“6.1 Clock adjustment”.

COOKING HOB CONTROL KNOB

These knobs provide control of the ceramic hob's cooking zones.

The zone it controls is shown above each knob. The knob shown on the right is
for the front left-hand cooking zone.
Turn the knob to the right to set the zone's operating power; the settings range
from a minimum of 1 to a maximum of 9.
The working power is shown by a display on the hob.

Heating accelerator

Each cooking zone is equipped with a heating accelerator.
This system allows the zone to be operated at peak power for a time proportional to the heating
power selected.
To start the heating accelerator, turn the knob to the left, select setting “A” and then release. The
letter “A” will appear on the display on the hob.
You now have 3 seconds to select the heating setting of your choice.

Once a setting between 1 and 8 has been selected, “A” and the chosen setting will flash in alternation
on the display.
While the heating accelerator is in operation, the heating level can be increased at any time. The "full
power" time will be modified accordingly.
Conversely, the heating level cannot be reduced. If the knob is turned to the right while the heating
accelerator is in operation, this will stop it immediately.
