18 CV501 - 16CH
Note: The button works as the enter key. This must be pressed to save changes. The works as the escape button, and
when pressed will exit the screen and not save any changes.
The main menu consists of nine options:
1. Camera Setup
2. Motion Setup
3. Record Setup
4. Alarm Setup
5. HDD Management
6. Network Setup
7. Backup Setup
8. System Setup
9. Exit
MAIN MENU
As you navigate through the Menu of the DVR, you will notice that most fields are adjustable. If the Menu setting has to the right of it, you can
adjust the value by either using the left and right directional buttons, or scrolling up or down with the mouse wheel. If the Menu setting has
next to it, you can select this button by pressing ENTER or by clicking on the SET button with the mouse. Clicking SET will enter a sub menu which
will allow you to adjust sub-settings for the DVR.
To call up the Main Menu:
The Main Menu can be called by 2 different options:
Option 1:
1. Press the Menu button the DVR front panel or on the remote control.
Option 2:
1. Scroll the mouse to the bottom of the screen to reveal Pop Up Menu Bar.
2. Click the
to call up the Main Menu.
MAIN MENU
