7-18
WHEN THE GRAPHIC SYMBOLS FLASH ON THE TOUCH PANEL
2
A
Paper Misfeed in the Finisher (optional)
4. CLEAR PAPER SYMBOL (Cont.)
2 Rotate the blue knob to locate the arrow within the
area A on the label.
- Under this condition, the punchers are up, allowing the pa-
per shown in the figure to be removed.
1 Open the upper cover of the finisher.
1
2 Lift knob (See the upper right figure), then remove
any misfed paper.
- For the paper misfed in the position shown on the right, pull
the knob in the direction of the arrow, then remove it.
Knob
Knob
Knob
Knob
