Getting Started 1-13
Magnetic Stripe Reader
The snap-on Magnetic Stripe Reader (MSR) allows easy data capture with the swipe of a magnetic stripe card. The MSR snaps easily
on to the bottom of the mobile computer and can be removed when not in use.
Attaching the MSR
To attach the MSR, slide the MSR onto the bottom of the mobile computer, and secure by pressing the arms into the mobile computer.
Figure 1-13. MSR Installation
To remove the MSR, open the arms from the MSR, and pull the MSR from the mobile computer.
Using the MSR
To use the MSR, the mobile computer must have an application installed which accepts magnetic stripe data. The MC50 has a mobile
computer sample application installed which can be used to access data acquired by the MSR. Start the sample application. Swipe
Card Reader Slot
Arm
