3-1
PFV-L10
IC
DIODE Page LED Page
Semiconductors of which functions are equivalent are described
here. For parts replacement, refer to the section of Spare Parts in
this manual. The circuit diagram of each IC is obtained from the
IC data book published by the manufacturer.
TRANSISTOR Page IC Page
Section 3
Semiconductor Pin Assignments
Index
LM393PS ......................... 3-3
LM393PS-E20 .................. 3-3
SN74HC02ANS ............... 3-3
SN74HC02ANSR ............. 3-3
TC7W00F ......................... 3-3
TC7W00F(TE12R) ........... 3-3
TC7W08F ......................... 3-3
TC7W08F(TE12R) ........... 3-3
2SA1444-L ....................... 3-2
2SB1375 .......................... 3-2
DTA124EKA-T146 ............ 3-2
DTC124EKA-T146 ........... 3-2
FMG1 ............................... 3-2
FMG1T148 ....................... 3-2
550-3505 .......................... 3-2 1SS123-T1 ....................... 3-2
1SS226 ............................ 3-2
PA886C02 ........................ 3-2
