-35-
D('*0()$Jg\\[;i`ccGi\jj
G8
I
K
J
GXikjC`jk
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 XLABEL04 ELECTRICITY LABEL 54 XM1039054 ROUND KNOB M5-.8
2 XM1039002 CLOSE DOOR HORIZ LABEL 55 XPW02M FLAT WASHER 5MM
3 XLABEL08H READ MANUAL LABEL 56 XPS09M PHLP HD SCR M5-.8 X 10
4 XLABEL06 RESP/GLASSES LABEL 57 XPS14M PHLP HD SCR M6-1 X 12
5 XPSB14M CAP SCREW M8-1.25 X 20 58 XPW03M FLAT WASHER 6MM
6 XM1039006 QUILL CLAMP 59 XM1039059 CENTER PULLEY
7 XPN03M HEX NUT M8-1.25 60 XPR02M EXT RETAINING RING 14MM
8 XM1039008 DEPTH STOP SCALE STUD 61 XP6202 BALL BEARING 6202
9 XM1039009 DEPTH STOP BRACKET 62 XM1039062 CENTER SHAFT
10 XPW02M FLAT WASHER 5MM 63 XPVA26 V-BELT A-26 4L260
11 XPS05M PHLP HD SCR M5-.8 X 8 64 XPSS01M SET SCREW M6-1 X 10
12 XPN31M HEX NUT M12-1.5 65 XPK23M KEY 5 X 5 X 25
13 XPLW10 LOCK WASHER 3/4 66 XM1039066 MOTOR PULLEY
14 XPN03M HEX NUT M8-1.25 67 XM1039067 MOTOR 1-1⁄2HP
15 XPSS21M SET SCREW M8-1.25 X 25 67-1 XM1039067-1 MOTOR FAN
16 XM1039016 INDICATOR 67-2 XM1039067-2 CAPACITOR COVER
17 XM1039017 DEGREE SCALE 67-3 XM1039067-3 S CAPACITOR 400MFD 250VAC
18 XPR21M INT RETAINING RING 35MM 67-4 XM1039067-4 WIRING BOX COVER
19 XM1039019 STRAIN RELIEF 67-5 XM1039067-5 FAN COVER
20 XM1039020 UNPLUG LABEL 68 XPN02M NUT M10-1.5
21 XM1039021 DP LIGHTS LABEL 69 XPW04M FLAT WASHER 10MM
22 XM1039022 SHOP FOX BLACK/AL LABEL 70 XM1039070 MOTOR BASE
23 XM1039023 SPEED CHART M1039 71 XM1039071 SLIDE BAR (RIGHT)
24 XM1039024 MACHINE ID LABEL 72 XM1039072 SLIDE BAR (LEFT)
25 XM1039025 SLEEVE MT#4 73 XM1039073 SHIFTER
26 XPWRCRD110L POWER CORD 110V, LONG 74 XPB03M HEX BOLT M8-1.25 X 16
26-1 XM1039026-1 WIRE GASKET 75 XM1039075 HEADSTOCK
26-2 XM1039026-2 MOTOR CORD 76 XM1039076 CLAMP CORD
27 XM1039027 DRIFT KEY 77 XPS14M PHLP HD SCR M6-1 X 12
28 XPAW04M HEX WRENCH 4MM 78 XPSW08 SWITCH 110V WITH KEY
29 XPAW03M HEX WRENCH 3MM 78-1 XM1039078-1 SWITCH PLATE
30 XM1039030 LIGHT DUST PLUG 78-2 XPHTEK6M TAP SCREW M4 X 16
31 XM1039031 LIGHT SOCKET 78-3 XM1039078-3 SWITCH KEY
32 XM1039032 LIGHT BASE 79 XM1039079 SWITCH (LIGHT)
33 XM1039033 SWITCH BOX 80 XPS08M PHLP HD SCR M5-.8 X 12
34 XM1039034 CHUCK KEY 81 XM1039081 SPRING COVER
35 XM1039035 CHUCK JT3 X 1-16MM 82 XM1039082 FLAT COIL SPRING
36 XM1039036 ARBOR JT3 x MT#4 83 XM1039083 SPRING CAP
37 XM1039037 SPINDLE 84 XPN31M HEX NUT M12 X 1.5
38 XP6206 BALL BEARING 6205 85 XM1039084 SPEC SET SCREW M10-1.5 X 30
39 XM1039039 SPINDLE SLEEVE 86 XPN02M HEX NUT M10-1.5
40 XM1039040 RUBBER WASHER 87 XPN03M HEX NUT M8-1.25
41 XP6206 BALL BEARING 6206 88 XPW01M FLAT WASHER 8MM
42 XM1039042 TAB WASHER 89 XPB07M HEX BOLT M8-1.25 X 25
43 XM1039043 ROUND NUT 90 XM1039091 KNOB BOLT M10-1.5 X 35
44 XPR37M EXT RETAINING RING 32MM 91 XM1039092 SHIFTER BAR
45 XP6207 BALL BEARING 6207 92 XPR05M EXT RETAINING RING 15MM
46 XM1039046 SPACER 93 XM1039088 ROLL PIN 8 X 105MM
47 XP6207 BALL BEARING 6207 94 XM1039089 SET SCREW M10-1.5 X 30
48 XPR26M INT RETAINING RING 52MM 95 XPB01M HEX BOLT M10-1.5 X 30
49 XM1039049 PULLEY INSERT 95-1 XM1039095-1 PLASTIC LOCK CAP
50 XM1039050 SPINDLE PULLEY 96 XM1039096 STAFF GAUGE
51 XM1039051 PULLEY NUT 97 XM1039097 FEED HANDLE KNOB M12-1.75
52 XPVA32 V-BELT A-32 4L320 98 XM1039098 HANDLE
53 XM1039053 PULLEY COVER 99 XM1039099 HANDLE BODY
