-13-
D('*0()$Jg\\[;i`ccGi\jj
J<
K
LG
The column must be secured on the base to properly
assemble your drill press.
Kfj\Zli\k_\Zfcldekfk_\YXj\#[fk_\j\jk\gj1
(% Place the column on the base and align the mount-
ing holes.
)% Secure the column to the base with the four M12-1.75
x 45 hex bolts, as shown in =`^li\/.
:fcldeXe[9Xj\
=`^li\/% Column secured to base.
Hex Bolts
=`^li\0% Pinion correctly installed in
table bracket.
The table bracket must be installed as described to prop-
erly assemble your drill press.
Kf`ejkXcck_\kXYc\jlggfik#[fk_\j\jk\gj1
(% Place the pinion in the table bracket, as shown in
=`^li\0, so the pinion and gear teeth mesh togeth-
er.
)% Mark the top of the rack, as shown in =`^li\(', to
keep track of which end is up.
*% Remove the column ring by loosening the setscrew,
and remove the rack.
KXYc\9iXZb\k
=`^li\('% Marking the top of the rack.
Column
Ring
Marking
Location
Rack
Continued on next page
