-16-
D('*0()$Jg\\[;i`ccGi\jj
J<
K
LG
The drill chuck attaches to the spindle by means of the
arbor, shown in
=`^li\(.. Matched tapers on the arbor
and the inside of the chuck create a semi-permanent
assembly when properly joined.
KfXjj\dYc\k_\[i`ccZ_lZbXe[dflek`kkfk_\jg`e$
[c\#[fk_\j\jk\gj1
(% Use mineral spirits to thoroughly clean the drill
chuck, arbor, and spindle sockets and dry all sur-
faces before assembly. Follow all safety warnings
on the container of the mineral spirits.
=X`cli\kf
Zc\Xek_\dXk`e^jli]XZ\jdXpZXlj\k_\kXg\i\[
]`kkfcffj\e[li`e^fg\iXk`fe#i\jlck`e^`ej\gXiX$
k`feXe[XelejX]\Zfe[`k`fe%
)% Use the chuck key to adjust the jaws of the drill
chuck until they are inside the drill chuck body.
*% Place the drill chuck face down on a workbench.
The arbor has a short taper and a long taper. Place
the short taper into the socket in the back of the
drill chuck and tap it with a rubber or wooden mal-
let, as shown in
=`^li\(/. If the chuck fails to
remain secure on the arbor, repeat Jk\gj( & *.
+% Slide the arbor into the spindle socket while slowly
rotating the drill chuck. The socket has a rectangu-
lar pocket into which the tang (or flat portion of the
arbor shown in
=`^li\(/) will fit.
,% Using a rubber mallet, seat the chuck as shown in
=`^li\(0.
;i`cc:_lZbXe[8iYfi
=`^li\(/% Seating the arbor into the
chuck.
=`^li\(.% Chuck components and tools.
JT3 Drill
Chuck
Chuck Key
MT4/JT3
Arbor
Drift Key
Tang-Side
Up
=`^li\(0% Seating the arbor and chuck
into the spindle.
;FEFKlj\Xjk\\c_Xdd\ifek_\[i`ccZ_lZbkf
j\Xkk_\XiYfi`ekfk_\jg`e[c\%Pfln`cc[XdX^\k_\
Z_lZbXe[&fijg`e[c\#n_`Z_dXpdXb\k_\dlelj$
XYc\filejX]\%
