-9-
D('*0()$Jg\\[;i`ccGi\jj
:
K
I
@:
8
C
We do not recommend using an extension cord for 220V
operation. When it is necessary to use an extension cord,
use the following guidelines:
• Use cords rated for Standard Service
• Never exceed a length of 50 feet
• Ensure cord has a ground wire and pin
• Do not use cords in need of repair
>ifle[`e^
This machine must be grounded! The electrical cord sup-
plied with this machine comes with a grounding pin. Do
not remove it. If converting to 220V operation, always
use a plug with a ground pin. If your outlet does not
accommodate a ground pin, have it replaced by a quali-
fied electrician or have an appropriate adapter installed.
Efk\1 N_\elj`e^XeX[Xgk\i#k_\X[Xgk\idljkY\
^ifle[\[%
(('M&))'MFg\iXk`fe
The E:AB8AJ ™ Model M1039 is prewired for 110V opera-
tion, but may be rewired for 220V operation. To do this,
consult the wiring diagram in the back of this manual.
Always connect this machine to a dedicated circuit (wire,
breaker, plug, receptacle) with a verified ground, using
the recommended circuit breakers and plugs/receptacles
listed at the bottom of this page.
Never replace a circuit breaker with one of higher amper-
age without consulting a qualified electrician to ensure
compliance with wiring codes.
@]pflXi\lejli\XYflk
k_\n`i`e^Zf[\j`epfliXi\XfigcXekfZfee\Zkpfli
dXZ_`e\kfXj_Xi\[Z`iZl`k#pfldXpZi\Xk\X]`i\_Xq$
Xi[ÇZfejlckXhlXc`]`\[\c\Zki`Z`Xekfi\[lZ\k_`ji`jb%
K_`j \hl`gd\ek dljk Y\ ^ifle[\[%
Le[\i ef Z`iZldjkXeZ\j j_flc[ k_\
^ifle[`e^ g`e Y\ i\dfm\[ ]ifd Xep
k_i\\$gife^\[ gcl^ fi j\i`flj `ealip
dXpfZZli%
6-15 P 6-15 R
=`^li\*% NEMA 5-15 and 6-15 plug wiring.
Fg\iXk`e^MfckX^\ 8dg;iXn 9i\Xb\iJ`q\ Gcl^&I\Z\gkXZc\
110V Operation 15 Amps 20A NEMA 5-15 12 Gauge, NEMA 5-15
220V Operation 7.5 Amps 15A NEMA 6-15 14 Gauge, NEMA 6-15
