5-22
S UPERSERVER 6012L-6 User’s Manual
PCI-X Bus Speed Setting
Jumpers P2 and JP4 are used to set
the speed of the PCI-X bus. The
default setting is PCI 66 MHz (the
other settings are to support future
PCI-X cards.) See the table on the
right for jumper settings.
33 MHz PCI Enable/Disable
If you wish to use 33 MHz PCI
cards, close J4 to force the 133
MHz PCI-X slot to run at 33 MHz.
See the table on the right for jumper
settings.
Note: if you force the slots to 33
MHz, you must set the PCI-X Bus
Speed jumpers (above) to the low-
est speed.
Ju m p e r
P o sitio n
O p e n
C lo se d
D e fin itio n
N o rm a l
3 3 M H z P C I
3 3 M H z P C I F o rc e
J u m p e r S e tting s
(J 2 9 /J P 4 )
SCSI Enable/Disable
The SCSI Enable/Disable jumper at
JA4 allows you to enable or dis-
able the onboard SCSI. The nor-
mal (default) position is enabled.
S e e t h e t a b l e o n t h e r i g h t f o r
jumper settings.
Ju m p e r
P o sitio n
P in s 1 -2
P in s 2 -3
D e fin itio n
E n a b le d
D isa b le d
S C S I E n a b le /D is a b le
J u m p e r S e tting s
(J A 4 )
SCSI Termination Enable/
Disable
Jumpers JPA1 and JPA2 allow you
to enable or disable termination for
the SCSI connectors. Jumper JPA1
controls SCSI channel A and JPA2
is for SCSI channel B. The normal
(default) setting is open to enable
(teminate) both SCSI channels. See
the table on the right for jumper set-
tings.
Ju m p e r
P o sitio n
O p e n
C lo se d
D e fin itio n
E n a b le d
D isa b le d
S C S I C h a n n e l T e rm in a tio n
E n a b le /D is a b le
J u m p e r S e tting s
(J P A 1 , J P A 2 )
Default setting is 66 MHz PCI.
P C I-X S lo t B u s S p e e d S e ttin g s
P in D e fin itio n s (P 2 , J P 4 )
P 2
P in s 1 -2
P in s 1 -2
P in s 2 -3
P in s 3 -4
P in s 4 -5
JP 4
C lo se d
O p e n
E ith e r (n /a )
E ith e r (n /a )
E ith e r (n /a )
S p e e d
3 3 M H z P C I
6 6 M H z P C I
6 6 M H z P C I-X
1 0 0 M H z P C I-X
1 3 3 M H z P C I-X
