5-14
S UPERSERVER 6012L-6 User’s Manual
Extra Universal Serial Bus
Connection (USB2/3)
Two USB headers are located at
J1 for front side USB access. The
odd numbered pins (toward the in-
side of the board) are for USB2
and the even numbered pins (to-
ward the edge of the board) are
for USB3. You will need a USB
cable (not included) to use each
of these connections. Refer to the
tables on the right for pin defini-
tions.
P in
N u m b e r
1
3
5
7
D e fin itio n
P o we r
-
+
G ro u n d
U S B 2 P in
D e fin itio n s (J 1 )
PWR_ON
The PWR_ON connection is lo-
cated on pins 1 and 2 of JF1. Mo-
mentarily contacting both pins will
power on/off the system. This
button can also be configured to
function as a suspend button (see
the Power Button Mode setting in
B I O S ) . T o t u r n o f f t h e p o w e r
when set to suspend mode, de-
press the button for at least 4
seconds. Refer to the table on the
right for pin definitions.
P in
N u m b e r
1
2
D e fin itio n
P W _ O N
G ro u n d
P W R _ O N C o n n e c to r
P in D e fin itio n s
(J F 1 )
P in
N u m b e r
2
4
6
8
D e fin itio n
P o we r
-
+
G ro u n d
U S B 3 P in
D e fin itio n s (J 1 )
Universal Serial Bus
(USB0/1)
Two Universal Serial Bus ports
are located beside the keyboard/
mouse ports. USB0 is the bottom
connector and USB1 is the top
connector. See the table on the
right for pin definitions.
U n ive rs a l S e ria l B u s P in D e fin itio n s
P in
N u m b e r D e fin itio n
1 +5 V
2 P 0 -
3 P 0 +
4 G ro u n d
5 N /A
P in
N u m b e r D e fin itio n
1 +5 V
2 P 0 -
3 P 0 +
4 G ro u n d
5 K e y
U S B 0 U S B 1
