Instructions for the User
10.5.3 Removing the self-cleaning liners
Remove all accessories from the inside of the oven and proceed as
follows:
1
Remove the side runners (fig.1);
2 Extract the side liners “F” and “G” (fig. 2);
3 Extract the back liner “A” after undoing the threaded ring-nut “C”
(fig. 2);
4 Replace the liners in their original positions.
1) 2)
10.6 Removing the door
10.6.1 Removing doors with mobile hinges
With the door completely open, lift the levers A of the two hinges until they
touch the hinges B and take hold of the two sides of the door with both
hands close to the hinges themselves. Raise the door to an angle of about
45° and remove it. If the hinges have not locked, repeat the operation,
raising the levers A and keeping the door slightly raised. To reassemble, fit
the hinges B into their grooves, then lower the door into place, ensuring
that it remains fitted into the grooves C, then lower the levers A.
