3-12
LS 1000 Product Reference Guide: Chapter 3, Maintenance and Specifications
* active low
Table 3-4. Pinouts - LS 1004
Pin LS 1004 Function
1 Data Data Line (for
synapse)
2 VBAT Power Supply
3 GND Ground
4 RTS Request to Send (for
RS-232C)
5 RXD* Receive Data Input
(for RS-232C)
6 N.C. Non-Connected (for
RS-232C)
7 DTR Data Terminal Ready
(for RS-232C)
8 TXD* Transmit Data
Output (for RS-232C)
9 CTS Clear to Send (for RS-
232C)
10 Clock Clock Line (for
Synapse)
