LS 1000 Product Reference Guide: Chapter 3, Maintenance and Specifications
* active low
Table 3-3. Pinouts - LS 1000
Pin LS 1000 Function
1 VBAT Power Supply
2 VBAT Power Supply
3 GND Ground
4 ENABLE Scan Enable
5 SOS Start of Scan
6 TRIGGER* Trigger Signal
7 DECODE Successful Decode
8 DBP Digital Bar Pattern
9 N.C. Non-Connected
10 N.C. Non-Connected
