Place a
3/8” ID flat washer on the second bolt. Slide the
second bolt through the bracket holes from the front of the
vehicle to the rear. Place a washer, then connector
assembly bracket tab (110-0080-000), on bolt. Ensure the
tongue and tab extends around the sensor end. (Figure 12-
B, previous page)
27. Place a hex nut on each bolt and hand-tighten.
When tightening the sensor mounting bolts, you
must torque the nut, not the bolt head.
28. Tighten the nut on the cable end of the sensor to 25 ft-
lbs of torque. Use torque wrench on the nut, not on the
bolt head. Torque will be increased in Step 30.
29. Tighten the nut on the non-cable end of the sensor to
25 ft-lbs of torque. Use torque wrench on the nut, not on
the bolt head. Torque will be increased in Step 31.
30. Tighten the nut on the cable end of the sensor to 50 ft-
lbs of torque. Use torque wrench on the nut, not on the
bolt head.
31. Tighten the nut on the non-cable end of the sensor to
50 ft-lbs of torque. Use torque wrench on the nut, not on
the bolt head. Check A/D readings at this time using the
display in the cab (comlink and sensor must be connected to
display and powered up) or the Deflection Sensor Test
Device per Step 37.
