19
12. The band clamps should be very tight. If necessary, to
make the bracket assembly parallel to the axle length,
loosen the band clamps and readjust the bracket assembly.
Then retighten the band clamp.
13. Remove the filament tape (350-0041-000) from the top
of the bracket assembly and discard.
14. Temporarily unscrew one of the bolts (131-0037-001) in
the bracket assembly from its nut (132-0014-000) and
remove the bolt from the bracket assembly. Ensure the
unfastened side of the alignment tool lifts easily in and out of
the bracket. If it binds, loosen one or both band clamps so
the brackets can be lined up and the alignment tool has free
play.
15. Reset the alignment tool and restore the bolt into the
bracket assembly and loosely fasten with its nut.
16. Remove any excess adhesive in the area around the
brackets, to ensure proper clearance when installing the
cover in the procedure’s final steps.
17. Allow time for the adhesive to cure, according to the
following table:
Ambient Temperature Fixture Time
32° F (0° C) 6 Hours
54° F (12° C) 3 Hours
72° F (22° C) 2 Hours
Cure time is 24 hours.
