SR850 Performance Test Record
9. DC Outputs and Inputs (continued)
Output Offset Lower Limit Reading Upper Limit
CH2 -100.00 9.960 V _______ 10.040 V
-50.00 4.960 V _______ 5.040 V
0.00 -0.020 V _______ 0.020 V
50.00 -5.040 V _______ -4.960 V
100.00 -10.040 V _______ -9.960 V
Output Voltage Lower Limit Reading Upper Limit
AUX1 -10.000 -10.040 V _______ -9.960 V
-5.000 -5.040 V _______ -4.960 V
0.000 -0.020 V _______ 0.020 V
5.000 4.960 V _______ 5.040 V
10.000 9.960 V _______ 10.040 V
Output Voltage Lower Limit Reading Upper Limit
AUX2 -10.000 -10.040 V _______ -9.960 V
-5.000 -5.040 V _______ -4.960 V
0.000 -0.020 V _______ 0.020 V
5.000 4.960 V _______ 5.040 V
10.000 9.960 V _______ 10.040 V
Output Voltage Lower Limit Reading Upper Limit
AUX3 -10.000 -10.040 V _______ -9.960 V
-5.000 -5.040 V _______ -4.960 V
0.000 -0.020 V _______ 0.020 V
5.000 4.960 V _______ 5.040 V
10.000 9.960 V _______ 10.040 V
Output Voltage Lower Limit Reading Upper Limit
AUX4 -10.000 -10.040 V _______ -9.960 V
-5.000 -5.040 V _______ -4.960 V
0.000 -0.020 V _______ 0.020 V
5.000 4.960 V _______ 5.040 V
10.000 9.960 V _______ 10.040 V
Page 3 of 4
7-27
