29
2. Press the same number as ID set in DVR on the remote
control.
3. An icon will be displayed on the Live Screen that corresponds
to the remote control ID number.0
The options are from 0 to 99
SENSOR Select sensor from 1 to 10.
TYPE Set the type of sensor for the specified channel. Options are:
OFF, NORMAL OPEN, and NORMAL CLOSE.
4-4-1. ALARM-OUT
Figure 4.4.2. ALARM-OUT Setup Screen
Table 4.4.2. Menu Item in ALARM-OUT Setup Screen
Item Description
ALARM OUT Select an Alarm out number.
SENSOR IN Enable Alarm Out by Sensor from 1 to 10 Inputs.
MOTION ON Enable Alarm Out by Camera Motion from 1 to 10 cameras.
VIDEO LOSS ON Enable Alarm Out by Video Loss from 1 to 10 cameras.
ALARM DURATION Set the alarm dwell time from 5 to 60 seconds.
ERROR ALARM Set the error type for the alarm beeping activation. The options are;
OFF, ALL, HDD ERROR and VIDEO LOSS.
