28
4-4. Setup – DEVICE
In the SETUP menu, select the DEVICE tab. Then, the device menu is displayed as pictured below.
Navigate through the menu items using the mouse or the control button on the remote control and change
the value of the menu item.
Figure 4.4.1. Device Mode Setup Screen
Table 4.4.1. Menu Items in Device Setup Screen
Item Description
ALARM OUT Set the sensor, motion, and video loss for triggering alarm relay.
HDD Error and Video Loss can trigger beeping.
CONTROLLER & PTZ Set the PTZ baud rate, protocol, and ID.
CHANNEL Select specified channel for motion zone setup.
SPOT OUT Set the spot out
MOTION ZONE Select either Full Zone or Partial Zone for motion sensing.
MOTION SENSITIVITY Set the motion sensitivity for the specified channel.
Control the motion sensitivity from 1 to 9.
KEY TONE Enable/disable key tone.
REMOTE CONTROL ID Select an ID of remote control.
1. Select ID number.
