Instructions for the user

3. DESCRIPTION OF CONTROLS

3.1 Front control panel

All the cooker controls and commands are on the front panel.

Single oven model

Before using the

oven

check that the electronic programmer is showing

the symbol

(see paragraph “3.2.1 Clock adjustment”.

DESCRIPTION OF SYMBOLS

FRONT RIGHT BURNER

OVEN VARIABLE
GRILL

BACK RIGHT BURNER

OVEN THERMOSTAT

BACK LEFT BURNER

OVEN FUNCTION

FRONT LEFT BURNER

COOKING HOB CONTROL KNOB

Standard heating
The circle next to each knob indicates the cooking
zone it controls. To heat, turn the knob to the desired
position (1 to 9). Adjustment is continuous so that
the appliance also operates at any intermediate value.
To turn off, return the knob to 0.
