Smooth Fitness USER WEIGHT LIMITATION CE7.4 User Manual
Page 8
8
SMOOTH CE7.4 ELLIPTICAL TRAINER
COMPLETE PARTS LIST
Item No.
Description
Qty.
Part No.
534
8x27x2mm Washer
2
CE7.4 – 534
535
8x14xT2.0mm Spring Washer
2
CE7.4 – 535
536
M42 C Clip
2
CE7.4 – 536
537
18x10x5.1mm Washer
4
CE7.4 – 537
538
M5x12mm Screw
8
CE7.4 – 538
540
10x18x3mm Washer
2
CE7.4 – 540
541
10x94 – M12x22mm Bolt
1
CE7.4 – 541
542
Compression Spring
1
CE7.4 – 542
543
M12 Nylon Nut
1
CE7.4 – 543
544
Magnet
2
CE7.4 – 544
545
M6x40mm Bolt
1
CE7.4 – 545
600
601
Rear Cover – Left
1
CE7.4 – 601
602
Front Cover – Left
1
CE7.4 – 602
603
Rear Cover – Right
1
CE7.4 – 603
604
Front Cover – Right
1
CE7.4 – 604
605
Top Cover
1
CE7.4 – 605
606
Pedal
2
CE7.4 – 606
607
Pedal Cover
4
CE7.4 – 607
608
Pedal Soft Cushion
2
CE7.4 – 608
609
Wheel Cover
2
CE7.4 – 609
611
Oval Tube Cap
2
CE7.4 – 611
612
Power Switch Plate Cover
1
CE7.4 – 612
613
Tube Cap
2
CE7.4 – 613
615
Rear Pedal Cover
2
CE7.4 – 615
616
Action Handle Bar Shaft Bushing
2
CE7.4 – 616
617
Front Handlebar End Cap
2
CE7.4 – 617
618
Front Frame Cover – Left
1
CE7.4 – 618
619
Front Frame Cover – Right
1
CE7.4 – 619
621
Level Adjuster
2
CE7.4 – 621
622
Rubber Cap
2
CE7.4 – 622
623
Rubber Cushion – Front
2
CE7.4 – 623
624
Rubber Cushion – Rear
2
CE7.4 – 624
625
Belt
1
CE7.4 – 625
626
Rubber Wire Holder
1
CE7.4 – 626
636
Plastic Fixing Insert
7
CE7.4 – 636
637
Rear Stabilizer Cap
2
CE7.4 – 637
638
Rear Stabilizer Mat
2
CE7.4 – 638
654
Pedal Arm Front Pivot Cover
4
CE7.4 – 654
655
Pin Nut
2
CE7.4 – 655
656
Console Back Cover
1
CE7.4 – 656
657
Water Bottle
1
CE7.4 – 657
659
Chest Belt
1
CE7.4 – 659
