4 SMOOTH CE7.4 ELLIPTICAL TRAINER
SUPPLIED HARDWARE
This list identifies the hardware you will use to assemble the product. To help distinguish between
the various types of screws and bolts, use the scale below to measure them and compare them to
the sizes listed.
No. Description Qty.
701 M6x35mm Allen Head Bolt 2
702 M8x40mm Allen Head Bolt 2
703 20x91--M14x25mm Bolt 2
704 M14 Nut 2
705 8x14x2mm Spring Washer 2
706 20.7x29.1x0.3mm Washer 2
A Screwdriver – L 1
B 5mm Allen Wrench 1
C 8mm Allen Key 1
D 19 x 35 Spanner 1
E Slotted Screwdriver 1
F 4mm Allen Wrench 1
702 701 703 704
705 706
A
B
D C E F
MILLIMETERS
