6 SMOOTH CE7.4 ELLIPTICAL TRAINER
COMPLETE PARTS LIST
Item No. Description Qty. Part No.
249 Tray Cap – Right 1 CE7.4 – 249
251 Crank Disk Support Cover 2 CE7.4 – 251
252 Crank Disk Axle 1 CE7.4 – 252
253 25x35xT2.0 Washer 1 CE7.4 – 253
254 Crank Disk Oval Cap 2 CE7.4 – 254
255 Crank Disk Cover 2 CE7.4 – 255
256 Crank Disk 1 CE7.4 – 256
257 Left Crank 1 CE7.4 – 257
258 Right Crank 1 CE7.4 – 258
259 Crank Axle Bushing 1 CE7.4 – 259
261 Pedal Arm Support Axle 19x80.4mm 1 CE7.4 – 261
262 Pedal Arm Support Axle 19x104.4mm 1 CE7.4 – 262
264 3/4” Nut 2 CE7.4 – 264
266 M8x15mm Allen Head Bolt 4 CE7.4 – 266
267 M6x12mm Allen Head Cap Bolt 2 CE7.4 – 267
268 M8x20mm Bolt 2 CE7.4 – 268
269 8x14xT2.0 Spring Washer 6 CE7.4 – 269
270 M6x12mm Screw 1 CE7.4 – 270
271 10x16x1.5mm Washer 3 CE7.4 – 271
272 6x10x1mm Spring Washer 2 CE7.4 – 272
273 Fan Bracket – Top 1 CE7.4 – 273
274 Fan Bracket – Bottom 1 CE7.4 – 274
275 Adjustable Vane 1 CE7.4 – 275
276 iPod Dock Bracket Cover – Top 1 CE7.4 – 276
277 iPod Dock Bracket Cover – Bottom 1 CE7.4 – 277
278 6x14.5-M5x6.5mm Bolt 2 CE7.4 – 278
279 6x8x8mm Washer 2 CE7.4 – 279
285 Bearing Sleeve 1 CE7.4 – 285
286 M8x30mm Allen Head CAP Bolt 2 CE7.4 – 286
287 M10x25mm Allen Head CAP Bolt 2 CE7.4 – 287
288 Bushing 25X32X6mm 2 CE7.4 – 288
289 19x25x6mm Washer 1 CE7.4 – 289
300
301 Action Handlebar Foam Grip 2 CE7.4 – 301
302 Hand Pulse Sensor 2 CE7.4 – 302
303 Action Handlebar End Cap 2 CE7.4 – 303
304 Bearing 6004 4 CE7.4 – 304
305 Action Handlebar Cover 2 CE7.4 – 305
306 Action Handlebar Front Cover 4 CE7.4 – 306
307 4x12mm Plastic Screw 8 CE7.4 – 307
308 4x12mm Screw – Cone Point 8 CE7.4 – 308
309 Action Handlebar Side Cap 2 CE7.4 – 309
310 Hand Pulse Sensor Back Cover 2 CE7.4 – 310
