COMPLETE PARTS LIST
Item No. Description Qty. Part No.
100
101 Console Support Tube 1 CE7.4 – 101
102 Main Frame 1 CE7.4 – 102
103 Pedal Arm – Left 1 CE7.4 – 103
104 Pedal Arm – Right 1 CE7.4 – 104
105 Action Handlebar – Left 1 CE7.4 – 105
106 Action Handlebar – Right 1 CE7.4 – 106
107 Upright 1 CE7.4 – 107
109 Chain Cover Support Tube 1 CE7.4 – 109
110 Tension Wheel Bracket 1 CE7.4 – 110
111 Pedal Support Base 2 CE7.4 – 111
112 Magnet Bracket 1 CE7.4 – 112
113 Motor Bracket 1 CE7.4 – 113
200
201 Flywheel Axle 1 CE7.4 –201
202 Flywheel 1 CE7.4 –202
203 Aluminum Disk 1 CE7.4 –203
204 Flywheel Axle Support 1 CE7.4 –204
205 Flywheel Fan Pieces 4 CE7.4 –205
206 Bearing 6000 3 CE7.4 –206
207 M10 C Clip 2 CE7.4 – 207
208 M8 x 15mm Allen Head Cap Bolt 4 CE7.4 – 208
209 8 x 14 x T2.0 Spring Washer 4 CE7.4 – 209
211 M5 x 12mm Bolt 8 CE7.4 – 211
212 Magnetic Sensor 1 CE7.4 –212
213 M4 x 15mm Screw 2 CE7.4 – 213
214 M4 Nylon Nut 2 CE7.4 – 214
215 10x18x0.3mm Washer 2 CE7.4 – 215
216 4x8mm Screw – Cone Point 4 CE7.4 – 216
217 4x10mm Screw – Flat Point 2 CE7.4 – 217
218 M5 Nut 4 CE7.4 – 218
219 M5x10mm Allen Head Bolt 4 CE7.4 – 219
220 3x12mm Screw – Flat Point 4 CE7.4 – 220
231 Console Housing - Upper 1 CE7.4 – 231
232 Console Insert 1 CE7.4 – 232
233 Speaker Cover 1 CE7.4 – 233
235 Console Housing – Bottom 1 CE7.4 – 235
239 3x10mm Screw – Flat Point 11 CE7.4 – 239
241 4x12mm Screw – Flat Point 10 CE7.4 – 241
242 M6 Nylon Nut 1 CE7.4 – 242
245 iPod Dock Cap 1 CE7.4 – 245
247 Tray 1 CE7.4 – 247
248 Tray Cap – Left 1 CE7.4 – 248
