Instructions for the installer
35
Never use the oven door to lever the oven into
place when fitting.
Avoid exerting too much pressure on the oven
door when open.
2.3 Connecting the cook top to the oven
Once installed, the cook top must be connected to the oven. Mount the
oven allowing enough room for the following operations to be made.
• Connect the earth wire (yellow-green) of the cook top to the earth
terminal A of the oven (see figure).
• Fit the cook top connectors into the appropriate sockets in the top
cover of the oven. Make sure that the colours and symbols of the
connectors match those of the oven sockets.
• If the cook top is equipped with a connector for the residual heat
indicator, same must be fitted into the free socket on the right side.
The oven can now be fully mounted into the cabinet; make sure that the
power cable is properly routed and does not come into contact with parts
which may become hot during operation.
