ASUS A8V-X 2-25
2.4.5 Onboard Devices Configuration
Onboard Floppy Controller [Enabled]
Serial Port1 Address [3F8/IRQ4]
Serial Port1 Mode [Normal]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Onboard Game Port [Disabled]
Onboard MIDI Port [Disabled]
Onboard Floppy Controller [Enabled]
Enables or disables the onboard floppy controller.
Configuration options: [Disabled] [Enabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Serial Port1 Mode [Normal]
Allows you to select the Serial Port1 mode. This item appears only
when the Serial Port1 item is not Disabled.
Configuration options: [Normal] [IrDA] [ASK IR]
LDT to AGP Local Frequency [1000 MHz]
LDT to AGP Local (Upstream) [16 BIT]
LDT to AGP Width (Downstream) [16 BIT]
HyperTransport Configuration
LDT to AGP Local Frequency [1000 MHz]
Sets the LDT to AGP frequency. Configuration options: [200 MHz]
[400 MHz] [600 MHz] [800 MHz] [1000 MHz]
LDT to AGP Local (Upstream) [16 BIT]
Configuration options: [8 BIT] [16 BIT]
LDT to AGP Local (Downstream) [16 BIT]
Configuration options: [8 BIT] [16 BIT]
