90 US
When you select “PHASE
INFO.”
You can check the phase of each speaker (in
phase/out of phase).
Press V/v repeatedly to select a speaker,
then press to return to step 2 in
“To confirm/save Auto Calibration when
GUI function is turned off” (page 89).
* xxx represent a speaker channel.
FL Front left
FR Front right
CNT Center
SL Surround left
SR Surround right
SB Surround back
SBL Surround back left
SBR Surround back right
SW Subwoofer
Tip
Depending on the position of the subwoofer, the
measurement results for polarity may vary.
However, there will be no problems even if you
continue to use the receiver with that value.
For details on each sound field type, see
“Enjoying Surround Sound” (page 63).
Press 2CH/A.DIRECT, A.F.D.,
MOVIE, or MUSIC repeatedly.
The selected sound field type appears on the
display.
To select Enhanced Surround
Mode
1 Press AMP.
2 Press MENU.
3
Press V/v repeatedly to select
“”, then press or b.
4 Press V/v repeatedly to select
“”, then press or b.
5 Press V/v repeatedly to select the
Enhanced Surround Mode you want,
then press
.
Note
The selected Enhanced Surround Mode can only be
applied if you have selected “E.SURROUND” by
pressing A.F.D. repeatedly.
Press 2CH/A.DIRECT repeatedly to
select “A.DIRECT”.
Display Explanation
xxx *
: IN The speaker is in phase.
xxx *
: OUT The speaker is out of phase. The
“+” and “–” terminals of the
speaker may be connected the
other way around. However,
depending on the speakers,
“xxx:OUT” appears on the
display even though the speakers
are connected properly. This is
because of the speakers’
specifications. In this case, you
can continue to use the receiver.
xxx *
– – – No speakers are connected.
Selecting a sound field type
Listening to the sound without
any adjustment (ANALOG
DIRECT)
