Additional Information
34 EN
Specifications
System MiniDisc digital audio system
Disc MiniDisc
Laser Semiconductor laser ( λ = 780 nm)
Emission duration: continuous
Laser output Less than 44.6 µW*
* This output is the value measured at a
distance of 200 mm from the objective
lens surface on the Optical Pick-up
Block with 7 mm aperture.
Laser diode properties Material: GaAlAs
Revolutions (CLV) 400 rpm to 900 rpm
Error correction Advanced Cross Interleave Reed
Solomon Code (ACIRC)
Sampling frequency 44.1 kHz
Coding Adaptive Transform Acoustic Coding
(ATRAC)
Modulation system EFM (Eight-to-Fourteen Modulation)
Number of channels 2 stereo channels
Frequency response 5 to 20,000 Hz ±0.3 dB
Signal-to-noise ratio Over 96 dB during playback
Wow and flutter Below measurable limit
General
Power requirements
Dimensions (approx.) (w/h/d) incl. projecting parts
280
Ч
90
Ч
282.5 mm
(11 1 / 8
Ч
3 5 / 8
Ч
11 1 / 8 in.)
Mass (approx.) 2.8kg (6 lbs 3 oz)
Supplied accessories See page 4.
Optional accessories
Optical cable: POC-15A
Recordable MDs: MDW-60 (60 min), MDW-74 (74 min)
U.S. and foreign patents licensed from Dolby Laboratories
Licensing Corporation.
Design and specifications are subject to change without
notice.
Inputs
—
500 mVrms
Rated
input Minimum
input
125 mVrms
Input
impedance
47 kilohms
Jack type
Phono
jacks
DIGITAL IN
LINE
(ANALOG) IN
Square
optical
connector
jack Optical
wave
length:
660 nm
Outputs
Load impedance Jack type Rated output
DIGITAL
OUT
LINE
(ANALOG)
OUT
PHONES 32 ohms
Over 10 kilohms
Optical wave
length: 660 nm
10 mW
2 Vrms
(at 50 kilohms)
–18 dBm
Stereo
minijack
Phono
jacks
Square
optical
connector
jack
—
Power consumption
Where purchased
Continental Europe
US and Canada
UK and Hong Kong
Other countries
Where purchased
Other countries
UK and Hong Kong
Continental Europe
US and Canada
220 – 230 V AC, 50/60 Hz
220 – 240 V AC, 50/60 Hz
Power requirements
120 V AC, 60 Hz
110 – 120, 220 – 240 V AC,
50/60 Hz
20 W
20 W
Power consumption
19 W
20 W
