-6-
W1701 1HP Shaper
SA
FE
T
Y
Avoiding Potential Injuries
Figure 1. Use a SHOP FOX ® Featherboard as
anti-kick back protection.
Figure 2. Use rubberized SHOP FOX ® Push
Blocks to grip the workpiece when cutting.
Figure 3. Use the smallest insert the cutter will
allow to keep woodchips away from the inside of
shaper.
Figure 6. Unplug the shaper whenever making
adjustments or changing cutters.
Figure 4. Use SHOP FOX ® BOARD BUDDIES ® for
holding down the workpiece.
Figure 5. Use a SHOP FOX ® Right Angle Jig
when making special cuts without a safety guard.
NOTE: Guard Removed for Clarity. Always Use Guard.
NOTE: Guard Removed for Clarity. Always Use Guard.
NOTE: Guard Removed for Clarity. Always Use Guard.
NOTE: Guard Removed for Clarity. Always Use Guard.
