-9-
W1701 1HP Shaper
SE
T
U
P
• Machine Mobility: Use the Model D2057
SHOP FOX ® Heavy-Duty Mobile Base so
you can make the most out of your shop
space by moving the Model W1701 1HP
Shaper out of the way when not in use.
Contact your SHOP FOX ® Dealer for price
and availability.
• Working Clearances: Consider your
current and future shop needs with respect
to the machinery and the lumber to be
shaped. Allow enough space for safe
lumber support as the lumber is fed into
the shaper and as it exits the machine.
• Outlets: Make sure the electrical circuits
have the capacity to handle the amperage
requirements for your Model W1701 1HP
Shaper. Electrical outlets should be
located near the shaper, so power or
extension cords are clear of high-traffic
areas.
Cleaning Machine
The table and other unpainted parts of your
machine type are coated with a waxy grease
that protects them from corrosion during ship-
ment. Clean this grease off with a solvent clean-
er or citrus-based degreaser. DO NOT use chlo-
rine-based solvents such as brake parts cleaner
or acetone—if you happen to splash some onto a
painted surface, you will ruin the finish.
Machine Placement
The following is a description of the main com-
ponents shipped with the SHOP FOX ® Model
W1701. Lay the components out to inventory
them, and refer to the list below and
Figure 8 .
Main Contents Qty
A. Shaper Unit .....................................1
B. Stand Bolt Bag .................................1
— Carriage Bolts 5 ⁄
16
"-18 x 1 ⁄
2
" ............ 16
— Flat Washers 3 ⁄
8
" .......................... 16
— Hex Nuts 5 ⁄
16
"-18 .......................... 16
C. Stand Side Panels ..............................2
D. Fence Assembly ................................1
E. Table Inserts 1-3/8", 1-3/4" .................1
D. Special 26mm Flat Wrench ..................1
F. Wrenches 8, 14, 23, 26, 30mm .........1 Ea
G. Router Bit Collets 1/4", 1/2" & Nut ....1 Ea
H. Fence Faces ....................................2
I. Guard ............................................1
J. Fence Lock Studs 5/16"-20 ...................2
K. Guard Mounting Post ..........................1
L. Guard Attachment Bar ........................1
M. Miter Gauge Assembly ........................1
N. Tie Bars .........................................2
O. Knob and Fence Bolt Bag .....................1
— Star Knobs M8-1.25 .........................2
— Large Dia. Flat Washers 8mm ............2
— Hex Bolts M8-1.25 x 12 ....................2
— Phillips Head Screws M8-1.25 x 20 .......4
— Flat Washers 8mm ..........................6
— Phillips Head Screws M4-.7 x 10 .........2
— Hex Nuts M4-.7 ..............................2
P. Table Spacer Kit ...............................1
— Hex Bolt M12-1.75 x 30 ....................2
— Hex Bolt M12-1.75 x 40 ....................5
— Lock Washer 12mm .........................7
— Spacer 1/2" ..................................7
Inventory List
ALWAYS work in well-
ventilated areas far from
possible ignition sources
when using solvents to
clean machinery. Many
solvents are toxic when
inhaled or ingested. Use
care when disposing
of waste rags and
towels to be sure they
DO NOT create fire or
environmental hazards.
