-2-
W1701 1HP Shaper
IN
TR
O
DU
CT
IO
N
Woodstock Technical Support
We stand behind our machines! In the event that questions arise about your machine, parts are miss-
ing, or a defect is found, please contact Woodstock International Technical Support at (360) 734-3482 or
send e-mail to: [email protected]. Our knowledgeable staff will help you troubleshoot prob-
lems and send out parts for warranty claims.
INTRODUCTION
If you need the latest edition of this manual, you can download it from http://www.shopfox.biz.
If you have comments about this manual, please contact us at:
Woodstock International, Inc.
Attn: Technical Documentation Manager
P.O. Box 2309
Bellingham, WA 98227
Specifications
Motor Size ...................................................... 1HP, 110V, 60 Hz Single-Phase
Motor Speed ..............................................................................3,450 RPM
Amps .................................................................................................13
Spindle Size ....................................................................................... 1 ⁄
2
"
Spindle Max Cutter Height W/Bushings, Nuts, and Rub Collar ......................... 2 1 ⁄
2
"
Maximum Cutter Diameter .................................................................... 2 7 ⁄
8
"
Spindle Travel ..................................................................................... 7 ⁄
8
"
Spindle Speed .......................................................................... 13,200 RPM
Table Size .................................................................... 24" Wide x 19" Deep
Stand .........................................................................Powder Coated Paint
Footprint ................................................................18 7 ⁄
8
" Wide x 16 5 ⁄
8
" Deep
Dust Port ..........................................................................................N/A
Power Transfer .......................................................................... Belt Drive
Bearings ................................. Shielded and Permanently Lubricated Ball Bearings
Switch ...............................................................Forward and Reverse Toggle
Machine Weight ............................................................................. 200 lbs.
