Woodstock SHOP FOX W1701 - Manual (Page 32)

-29-
W1701 1HP Shaper
PA
RT
S
REF PART�# DESCRIPTION REF PART�# DESCRIPTION
400 X1701400 RUB�COLLAR�1/2"�X�13/16"�X�3/8" 431 XPSS01M SET�SCREW�M6-1�X�10
401 X1701401 CUTTER�SPINDLE 432 X1701432 MOTOR
402 X1701402 COLLET�NUT 432-1 XPC300S S.�CAPACITOR�200MFD�125VAC
403 X1701403 COLLET�1/4" 432-2 X1701432-2 CAPACITOR�COVER
404 X1701404 COLLET�1/2" 432-3 X1701432-3 WIRING�BOX�
405 X1701405 COLLET 432-4 X1701432-4 MOTOR�FAN
407 X1701407 SPINDLE�CARTRIDGE�ASSY 432-5 X1701432-5 MOTOR�FAN�COVER
407A X1701407A SPINDLE�CARTRIDGE 433 XPK01M KEY�5�X�5�X�22MM
408 XPK48M KEY�4�X�4�X�20MM 434 XPB20M HEX�BOLT�M8-1.25�X�35
409 X1701409 CLAMP�RING 435 XPLW04M LOCK�WASHER�8MM
410 XPR25M INT�RETAINING�RING�47MM 436 XPW02 FLAT�WASHER�3/8"
411 X1701411 WAVY�WASHER�45MM 437 XPB75M HEX�BOLT�M12-1.75�X�35
412 XP6204 BALL�BEARING�6204 438 XPW01 FLAT�WASHER�1/2"
413 X1701413 SPINDLE�HOUSING 439 X1701439 MOTOR�MOUNT�PLATE
414 X1701414 BALL�BEARING�SLEEVE 440 XPW02 FLAT�WASHER�3/8"
415 XP6204 BALL�BEARING�6204 441 XPN03M HEX�NUT�M8-1.25
416 X1701416 SPINDLE�PULLEY 442 XPLW05M LOCK�WASHER�12MM
417 X1701417 LOWER�SPINDLE�NUT 443 XPLW04M LOCK�WASHER�8MM
418 X1701418 BEARING�CONE 444 XPW06 FLAT�WASHER�1/4"
419 X1701419 COIL�SPRING 445 X1701445 TWO�CORD�CLAMP
420 XPSS20M SET�SCREW�M8-1.25�X�8 446 XPS14M PHLP�HD�SCR�M6-1�X�12
421 X1701421 SPRING�COLLAR 447 X1701447 FWD/REV�SWITCH
422 X1701422 STUD�M12-1.75�X�355 448 X1701448 SWITCH�BRACKET
423 X1701423 SLIP-ON�HANDLE 449 X1701449 TABLE�SPACER�KIT
424 X1701424 DRAW�BAR�M8-1.0�X�130 450 X1701450 FLAT�WRENCH�23MM
425 X1701425 TAPER�NUT�M8-1.25 451 X1701451 FLAT�WRENCH�26MM
426 X1701426 FLAT�BELT�690�X�10MM 452 X1701452 FLAT�WRENCH�30MM
427 XPB06M HEX�BOLT�M8-1.25�X�12 453 X1701453 RUB�COLLAR�1/2"�X�13/16"�X�1/2"
428 XPW02 FLAT�WASHER�3/8" 454 X1701454 HEX�BOLT�M12-1.75�X�40
429 X1701429 BELT�GUARD 455 X1701455 MITER�GAUGE�ASSEMBLY
430 X1701430 MOTOR�PULLEY
