SMSC USB97C242 Page 17 Revision 1.4 (05-03-07)
DATASHEET
PARAMETER SYMBOL MIN TYP MAX UNITS COMMENTS
O8 Type Buffer
Low Output Level
High Output Level
Output Leakage
V
OL
V
OH
I
OL
2.4
-10
0.4
+10
V
V
uA
I
OL
= 8 mA @ V
DDIO
= 3.3V
I
OH
= -4mA @ V
DDIO
= 3.3V
V
IN
= 0 to V
DDIO
(Note 7.1)
I/O8 Type Buffer
Low Output Level
High Output Level
Output Leakage
V
OL
V
OH
I
OL
2.4
-10
0.4
+10
V
V
µA
I
OL
= 8 mA @ V
DDIO
= 3.3V
I
OH
= -4 mA @ V
DDIO
= 3.3V
V
IN
= 0 to V
DDIO
(Note 7.1)
I/O12 Type Buffer
Low Output Level
High Output Level
Output Leakage
V
OL
V
OH
I
OL
2.4
-10
0.4
+10
V
V
µA
I
OL
= 12 mA @
V
DDIOE
= 3.3V
I
OH
= -6mA @ V
DDIO
= 3.3V
V
IN
= 0 to V
DDIO
(Note 7.1,Note 7.3)
I/O24 Type Buffer
Low Output Level
High Output Level
Output Leakage
V
OL
V
OH
I
OL
2.4
-10
0.4
+10
V
V
µA
I
OL
= 24 mA @ V
DDIO
= 3.3V
I
OH
= -12 mA @
V
DDIO
= 3.3V
V
IN
= 0 to V
DDIO
(Note 7.1,Note 7.3)
