17
Camera Control Command
• When no parameter is input for a command with
parameters, the screen displays the current parameters
of the command.
PARTIAL 1 0 15
OK
PARTIAL
1,0,15
• If an input value is out of parameter range, the
command is invalid and the screen displays “ERROR
SYNTAX.”
PARTIAL 1 0 20
ERROR SYNTAX
• If an invalid command name is input, the screen
displays “ERROR SYNTAX”.
PART 1 0 20
ERROR SYNTAX
• If the Enter key is pressed with no command input,
only the carriage return is carried out.
Command
Specifications
This section describes the details of control commands
available for the XCL-U1000C/U1000, classified by
category.
Camera Control Commands
Camera control commands fall into eight categories.
Category Description
AFE Sets AFE modes.
Shutter/Trigger Selects a shutter speed and a trigger mode.
WB Adjusts white balance.
DTL Adjusts edge enhancement.
Color Adjusts color matrix.
Gamma Sets
γ table.
Binning/Partial Selects a binning mode and a partial scan mode.
IN/OUT Sets input/output of a camera.
All the parameters used in camera control commands
are saved in a Flash ROM fitted with a microcomputer.
AFE Setting Commands
■ Gain-Step Setting
[Command] GAIN-STEP
[Parameter1] [dB]
[Process] Sets VGA gain value of AFE IC. The
value set in “0 dB gain auto adjustment”
is applied to “0 to 18 dB.”
■ Gain-Fine Adjustment Setting
[Command] GAIN-FINE
[Parameter1]
[Process] Devides “Gain-Step Setting” range (0 to
18 dB) into 522 portions and fine-tunes
VGA gain value of AFE IC.
■ Pedestal Setting
[Command] PEDESTAL
[Parameter1]
[Process] XCL-U1000: Sets AFE clamp level.
XCL-U1000C: Sets DSP offset level.
