S ERVICE S TRATO S TEAM C OUNTERTOP S TEAMER
Figure 15
Hot Surface Ignitor Does Not Glow Red
Hot surface ignitor does not glow red.
Replace transformer.
No Yes
Check connections to ignition
Module.
Replace ignitor module.
Replace ignitor. Check wiring to ignitor.
Is there 24V present at input to ignition
module?
Is there 24V output from the transformer?
Yes
No
No
Is there continuity between leads on
ignitor?
No
Yes
Is there 24V from ignitor
module to ignitor? Ignitor,
when operating, should draw
between 1 and 3 Amps.
Yes
P AGE 28 OF 50 O WNER ’ S M ANUAL 1185290
