68_ appendix
The Search Viewer screen consists of following:
1 This displays the IP address and the model
name of the connected DVR.
2 These menus consist of live, searCh,
setup, aBout.
3 These buttons are used for the screen split
and full screen mode.
4 This displays the IP address and the status
of the connected DVR.
5 These buttons are used for capture, print,
and save the image.
6 This displays a calendar at which you can
search the recorded video.
7 This displays a timeline at which you can
search the recorded video by the time.
8 These buttons are used for controlling
playback.
9 This displays the screen for playback of
recorded video.
• seQuenCe, previous, neXt buttons
are not available in searCh menu.
• Non-admin users do not have access to
searCh and setup menu.
SPLIT-SCREEN
You can change the split mode by clicking each number
icon.
QUAD MODE SINGLE MODE
USING Search Viewer
1
3
4
6
7
5
8
9
2
