56_ appendix
Alarm in
Alarm In recognize emergency in outer area and use with
recording, alarm, PTZ control.
1. Alarm in:
Select channel to setup Alarm In.
2. Linked camera:
Select camera which is linked with Alarm In. It records
connected camera together when event occurs.
3. Linked Alarm out:
You can set up emergency sound make when alarm in
make event.
network
connection
This DVR displays the network component informations
to provide video streaming function and remote control in
network.
1. obtain an iP Address Automatically (dhcP):
Dynamic address assignment is a type of receiving
address from DHCP. DVR which receive address
automatically from DHCP server displays network
address in system.
2. obtain dns server Address Automatically:
Displays IP address to main DNS server and assistant
DNS server.
 Please contact network administer or internet
service provider if you don’t know ip address or
network structure.
stream control
Set the network stream control for all cameras by frame
rate, resolution and quality.
1. camera:
It shows each camera number.
2. Frame:
Control the frame rate which is transferred by each
camera across the network.
3. resolution:
Set the resolution size to be transferred by each
camera across the network.
4. Quality:
Set the quality of picture to be transferred by each
camera across the network.
