SIIG 04-0373C User Manual
Page 7
7
For Existing Hard Drives with Data
1.
As the BIOS boots press either Ctrl+S or F4 when
prompted to enter the RAID BIOS.
2.
At the next screen select Create RAID Set, then
press Enter.
3.
At the next screen select Mirrored then press Enter.
4.
Select Manual configuration, then press Enter.
5.
Select the Source drive, press Enter.
6.
Select the Target drive, press Enter.
7.
At the Disk Copy window select Yes, then press
Enter.
8.
Select Offline copy, then press Enter.
9.
When asked Are You Sure (Y/N)?, press Y to begin
disk copy.
Note: Disk copy time is dependant on the size of the
mirrored set. Do not interrupt disk copy once
started.
10. After disk copy completes, press Ctrl+E to exit the
BIOS.
11. When asked Are you sure to exit (Y/N)?, press Y to
exit and reboot.
Rebuilding a Failed Mirror Set
When a failure to one member occurs, you will be notified
either by the RAID BIOS during boot or by the SATA Raid
GUI while in Windows. The steps below will guide you
in rebuilding a failed mirror set.
1.
Shutdown Windows, replace the failed hard drive,
then restart the system.
2.
During boot press either Ctrl+S or F4 to enter the
RAID BIOS.
