E-23
Setup & Connections
Rear Projection
• Place a translucent screen between the projector and
the audience.
• Use the projector’s menu screen to reverse the
projected image. (See page 42 for use of this
function.)
• Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and leveled.
Projection Using a Mirror
• When the distance between the projector and a
screen is not sufficient for normal rear projection, you
can use a mirror to reflect the image onto the screen.
• Place a mirror (normal flat type) in front of the lens.
• Project the normal image onto the mirror.
• The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
• When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
• It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
• Before mounting the projector, remove the Swivel
Stand. (See page 17 for removing and attaching the
Swivel Stand.)
• Before mounting the projector, contact your nearest
Sharp Authorized Service Center or Dealer to obtain
the recommended ceiling-mount bracket
(commercially available). (AN-CM260 ceiling-mount
bracket, AN-EP101B extension tube for AN-CM260.)
• When the projector is in the inverted position, use the
upper edge of the screen as the base line.
• Use the projector’s menu screen to select the
appropriate projection mode. (See page 42 for use
of this function.)
Ceiling-mount Projection
Image Projection
