General
Network Interface
RJ-45 (UTP Cable: EIA/TIA Categories 3, 4, 5)
BNC (Coax Cable: RG-58 A/U or RG-58 C/U)
AUI (Drop Cable)
Standards Supported
IEEE 802.3 and ISO/IEC 8802-3 10BASE-T (twisted-pair),
10BASE2 (thin coax) and 10BASE5 (thick coax)
Hardware Compatibility
IBM PC-XT, AT, 286, 386, 486, Pentium, PS2 Model 30,
and compatible, ISA-bus computers.
I/O Base Address
0200h to 03E0h on 20h boundaries
Interrupt Channel
2(9), 3, 4, 5, 10, 11, 12,15
Generic RPL Boot ROM
Size 16/32/64 KB selectable
Address 8 choices: C0000h to DFFFFh on 16 KB
boundaries
Dimensions
SMC1660BTA 157.35 mm x 101.6 mm (6.195 in. x 4 in.)
SMC1660T and SMC1660BT 157.35 mm x 62.99 mm
(6.195 in. x 2.48 in.)
A
PPENDIX
D
S
PECIFICATIONS
D-1
