6-0947 ACCESSORY, BAG-N-WAGON
(Hitch and Body Section)
ITEM
PART
NO.
DESCRIPTION
1
5-1935
ASSEMBLY, Hitch (Includes items 17 thru 30 & 40 thru 44)
2
4-0446
BODY, Wagon Cart
3
3-9604
SUPPORT,
Axle
4
3-1949
AXLE
5
5-2667
ASSEMBLY, Wheel/Tire, Pneumatic (Includes indented
items below) (may also use 5-1449 or 5-2305) (2)
--
1-0820
TIRE,
4.10/3.50x4
--
1-0819
RIM (Includes indented items below)
--
1-1807
BEARING, Ball (2)
--
1-4247
FITTING,
Lube
--
1-0821
TUBE,
Inner
6
3-1946
TONGUE
7
1-2391
GRIP,
Latch
8
3-7736
LATCH
9
1-3694
SPRING,
Latch
10
3-7737
YOKE
11
1-1032
WASHER, Felt (2)
12
1-0935
WASHER, 3/4” (6)
13
9-0364
PIN, 5/32 x 1” Cotter (2)
14
1-1022
COVER, Dust (2)
15
1-1713
PIN, 3/8 x 2-1/4” Clevis
16
1-1714
HAIRPIN,
3/32”
17
1-2388*
BALL,
Hitch
18
2-1762*
COLLAR,
Hitch
19
2-9562*
BAR, Upper Draw
20
3-7742*
BRACE, Draw Bar
21
3-7743*
BAR, Lower Draw
22
9-0160*
SCREW, 3/8-24 x 1” Hex Head Cap, Grade 5
23
9-0118*
WASHER, 3/8” Split Lock
24
9-0155*
NUT, 3/8-24 Hex, Grade 2
25
9-0247*
WASHER, 7/16” Split Lock
26
9-0460*
NUT, 7/16-20 Hex, Grade B
27
1-2389*
PIN, Hitch Clevis
28
9-0268*
SCREW, 1/2-20 x 1” Hex Head Cap, Grade 2
29
9-0819*
NUT, 1/2-20 Hex Jam Lock
30
1-5067*
HAIRPIN, 3/32 x 1-19/32”
31
1-2485
RETAINER, 1/4” Bolt (6)
32
9-0053
WASHER, 1/4” Internal Tooth Lock (8)
33
9-0063
NUT, 1/4-20 Hex (8)
34
1-1078
BOLT, 5/16-18 Shoulder
35
1-1079
WASHER,
Spring
36
9-0187
WASHER, 5/16” Split Lock
37
9-0196
NUT, 5/16-18 Hex
38
3-1038
DUST-CAP
(2)
39
9-0074
BOLT, 1/4-20 x 3/4” Short Neck Carriage, Grade 5 (6)
40
2-7713
CLIP,
Retaining
41
9-0206
SCREW, 5/16-18 x 3/4” Hex Head Cap, Grade 2
42
9-0203
SCREW, 5/16-18 x 1/2” Hex Head Cap, Grade 2
43
9-0391
WASHER, 5/16” Internal Tooth Lock
44
9-0184
NUT, 5/16-18 Hex Center Lock
45
1-6648
DECAL, Snapper (1-8593 may be used) (2)
46
1-2464
DECAL, Maximum Load
See Pages 38 and 39 for Dump Wagon Kit.
LT (Small Frame) ACCESSORIES
MANUAL No. 06613
HARDWARE BAG #6-0447 is comprised of
items 11, 12, 13, 14, 15, 16, 31 and 38
shown on this page.
*
KIT #6-0734 (Hitch Assembly)
is comprised of these items.
