15
NOTE: 6-1068 Catcher Adapter Kit must be installed before Grass catcher can be mounted.
6-1312 ACCESSORY, 38” SINGLE BAG GRASS CATCHER
(for Hydro Drive Models)
ITEM
PART NO. DESCRIPTION
1 6-1312 KIT, Single Bag Grass Catcher (Incl. Items 2 thru 28)
2 5-1948 TOP, Container (Includes Decal No. 1-1910)
3 2-9840 WASHER, Faceted (5)
4 4-7973 FRAME, Structure
5 3-7758 ROD, Bag
6 1-2556 CONNECTOR, Bag Rod
7 1-9251 BAG, Grass
7A 1-6108 SKIRT, Dust
8 3-1725 LATCH, Top
9 9-0532 SCREW, #10-32 Hex Head Cap, Grade 2
10 2-9841 PIN, 5/16 x 1-11/16” Clevis
11 2-6814 ADAPTER, 38” Deck
12 3-3995 BAFFLE
13 9-0376 NUT, #10-32 Hex Nyloc
14 9-1530 BOLT, 1/4-20 x 3/4” Short Neck Carriage, Grade 5 (3)
15 3-1951 LATCH, Tube
16 3-1952 BASE, Handle
17 9-1503 PIN, 3/32 x 1-1/2” Hair
18 9-1576 NUT, 1/4-20 Hex, Grade 5 or B (3)
18A 9-1314 WASHER, 1/4” Internal Tooth Lock (3)
19 9-0824 SCREW, 3/8-24 x 1-1/4” Hex Head Cap, Grade 5
(Blade Retaining Screw- not shown)
20 2-7915 TUBE, Grass
21 3-7745 HANDLE, Tube
22 6-0480 KIT, Air Lift (Includes items 22 thru 26)
23 9-0223 NUT, 5/16-24 Hex (6)
24 9-0391 WASHER, 5/16 Internal Tooth Lock (6)
25 3-7723 AIR-LIFT (2)
26 9-0228 SCREW, 5/16-24 x 11/16” Oval Head Machine, Grade 5
27 9-1575 NUT, 5/16-18 Hex Center Lock (4)
28 6-3289 KIT, Catcher, Debris Shield (Incl. items 29-32)
29 6-3287 SHIELD, Debris
30 9-0909 BOLT, 1/4-20 x 1-1/2” Hex (2)
31 9-1294 WASHER, 1/4” Flat (2)
32 9-1705 NUT, 1/4-20 Hex top Lock (2)
LT SERIES (Small Frame) MANUAL No. 06613
